| Resolution XGA (1024 x 768) |
| Brightness 15,000 ANSI Lumens (4-lamp mode); 7,500 ANSI Lumens (2-lamp mode) |
| Uniformity 90% (corner to corner) |
| LCD Panel System 1.8” TFT polysilicon type w/micro lens x 3 |
| Number of Pixels 2,359,296 (786,432 x 3) |
| Contrast Ratio 2000:1 (full on/off) |
| Aspect Ratio 4:3 |
| Power Lens Shift Up/Down Ratio 10:0 – 0:10 or 8:1 – 1:8 ; Left/Right Ratio 3:2 – 2:3 |
| Digital Keystone Correction +/- 40° (vertical) +/- 20° (Horizontal) |
| Projection Lamp 330W NSHA x 4 ( code 610-334-6267 ) |
| Scanning Frequency H Sync: 15-120kHz, V Sync: 48-120Hz |
| Dot Clock 230MHz |
| Color System PAL/PAL-M/PAL-N/SECAM/NTSC/NTSC4.43 |
| Computer Compatibility UXGA, SXGA+,SXGA, WXGA, XGA, SVGA, VGA, MAC |
| Voltage 240V AC,9.7 A Max, 50//60 Hz (auto sense/select) |
| BTU Rating 5800dB Rating 51dBA (Eco mode) |
| Power Consumption 1700W |
| Dimensions (WxHxD) 22.9″x9.9″x32.0″ |
| Net Weight 80.5lbs (w/o lens) |
| Detachable Input Panels |
| Board 1 Digital Visual Interface (DVI-D)• Analog(D-sub15) |
| Board 2 RGBHV & Component &Composite(5-BNC) •S-video (Mini DIN 4-pin)Optional Accessories |
| POA-MD18DVI DVI-Board |
| POA-MD13NET2 Network Board |
| POA-MD21WARP Warp&Blending Board |
| POA-MD17SDID HD-SDI & SD-SDI Input Board |
| POA-LNA02 Lens Mount Adapter (for LNS-W02, W02KS, M01, S01 lenses) |
| POA-LNA01 Lens Mount Adapter (for all other lenses) |
